SmartScope® Flash™ 635 (635 x 635 x 200 mm) – Provides measurement speed and stability. This design assures rapid, smooth part translation and robust measurement performance. An extended Y-axis travel of 610 mm is optional and either 300 mm or 400 mm extended Z-axis travel is available. Parts move on a precision DC motor-driven Y-axis stage while the optics assembly travels in the X-axis across a stable bridge cross member. SmartScope® Flash™ 500 (Contact us for XYZ Stage Travel details) – Offers all the great Flash features and performance in a large, travel bridge-design system. It also comes standard with a TTL coaxial illuminator and patented LED SmartRing™ light. A high-quality auto calibrating AccuCentric® 12:1 zoom lens provides excellent optical performance over its entire range. It contains a unique “elevating bridge” design and axial straightness and perpendicularity are built in to meet stringent volumetric specifications. Add optional through-the-lens (TTL) laser, touch probe or micro-probe to configure a highly capable multisensor system. With an expansive Z-axis of 250 mm (10 in.) to accommodate large parts, it combines state-of-the-art video and autofocus to deliver high productivity. SmartScope® Flash™ 302 (300 x 300 x 250 mm) – One of the most versatile benchtop systems OGP offers. It’s ideal for a wide variety of manufacturing industries including metalworking, plastics, biomedical, electronics, automotive, aerospace and more.
#Ogp smartscope software
Its heavy cast base and rigid steel column provide metrology integrity so accuracy can be maintained in real world environments. Like all Flash systems, it is equipped with OGP® Measure-X® metrology software and 12:1 AccuCentric® zoom optics. Its large 300 mm X travel makes it the system of choice for measuring critical dimensions of long parts on a benchtop machine. SmartScope® Flash™ 250 (300 x 150 x 200 mm) – A compact machine designed for easy access to the XY stage for maximum fixturing flexibility. SmartRing™ light is standard for the ultimate flexibility in surface illumination. The computer controlled LED array backlight tracks X-axis motion of the optics with no moving parts. It also has patented innovations that let users do more, faster. Innovative design features of “elevating bridge” and an embedded computer mean the system takes up little space on a benchtop while providing an ample measuring range and extensive measurement capabilities.
#Ogp smartscope series
It is also essential for the use of continuous scanning probes and double rotary tables.Īll machines of the ZIP series are available with a high intensity accessory lighting system called "VuLight" that allows you to measure in the most critical lighting conditions.With the B / W camera option you can still have a further increase in contrasts thanks to the "Frame Integrator" function: the system superimposes multiple images taken instantly with a consistent gain in brightness.SmartScope® Flash™ 200 (200 x 200 x 150 mm) – The smallest member of the Flash family of systems is a full-featured automatic measurement system.
With the ZIP series machines, the ZONE3 Multisensor measurement software is supplied as standard, which optimally manages the use of contact probes, lasers and rotary tables. Monitor magnifications range from 40 to 400x. The Zoom is self-calibrated throughout its run for precise measurements and perfect images. Tools of this type are universally recognized as extremely reliable and valid for every situation in the field of quality control and production.Įach SmartScope ZIP is equipped with Zoom AccuCentric ™ with a magnification ratio of 7: 1. SmartScope ZIP is a proven, fast and secure measurement system!
SmartScope ZIP Reliability and extreme precision!
